Motor setup

Louvolite OneTouch R1918 Wirefree

Range
LOUVOLITE (One Touch)
Motor
One Touch R1918 — Battery DC Motor
Remote
One Touch | 1CH R1920 | 16CH R1924
Power
Rechargeable battery DC
Identify by
R1918 on the motor. Check the remote number as well.
Work through a section in order. The response in the right column is how the motor confirms the step. If you don't get it, repeat that step rather than moving on. Stuck? Call 0436 666 687 with the model and what the motor is doing.

Before you start

  • Remote — insert battery.
  • Motor — fully charge.

Initial setup

Factory reset motor

Motor: PRESS & HOLD [BUTTON] — press 4 times, hold on the 5th until the motor joltsbeep x5 & jolt x2

Motor power on

Motor: HOLD [BUTTON]motor beep x1

Motor power off

Motor: HOLD [BUTTON]beep & jolt & extended beep

Pairing

Select channel
Motor: HOLD [BUTTON]beep & jolt
Remote: PRESS [UP]motor jolt x1

Reverse roll directionif required

Remote: HOLD [STOP]motor jolt x1
Remote: PRESS [DOWN]motor jolt x1

Set limits

UP limit FIRST
Remote back: PRESS [SET]motor jolt x1
Remote: HOLD [UP]continuous travel
Remote: PRESS [UP]step mode
Remote back: PRESS [SET]motor jolt x1
DOWN limit SECOND
Remote: HOLD [DOWN]continuous travel
Remote: PRESS [DOWN]step mode
Remote back: PRESS [SET]motor jolt x1
Remote back: PRESS [SET]motor jolt x1

Adjust upper limit

Move to upper limit
Remote back: PRESS [SET]motor jolt x1
Adjust height
Remote back: PRESS [SET]motor jolt x1

Adjust lower limit

Move to lower limit
Remote back: PRESS [SET]motor jolt x1
Adjust height
Remote back: PRESS [SET]motor jolt x1

Copy channel using motor — add channel or remote

Select channel
Motor: HOLD [BUTTON]beep & jolt
New channel: PRESS [UP]motor jolt x1

Delete channel on motor — delete channel or remote

Motor: HOLD [BUTTON]beep & jolt
Channel to delete back: PRESS [SET]motor jolt x1

Hide channel

Select last channel to keep
Remote: HOLD [STOP] [RIGHT]display flash CC

Unhide channel

Remote: HOLD [STOP] [RIGHT]display flash CC

Factory reset motor using remote

Remote: HOLD [STOP]motor jolt x1
Remote back: HOLD [SET]motor jolt x3

  • Factory Reset Motor

  • Pairing to Remote Control

  • Reverse Roll Direction

  • Set Limits

  • Adjust Upper Limit

  • Adjust Lower Limit

  • Copy Channel and Settings to Another Channel

  • Copy Channel and Settings to Another Remote

  • Delete Channel Using Remote

  • Copy Channel and Settings Using Motor

  • Delete Channel Using Motor

Troubleshoot

  • Hide Unused Channels on Remote

  • Unhide Unused Channels on Remote

User preferences

Set favourite positionmax 4 positions

Move to position
Remote back: PRESS [SET]motor jolt x1
Remote back: PRESS [SET]motor jolt x1
The motor will automatically stop at a favourite position when passing

Edit favourite position

Move to the position to edit
Remote back: PRESS [SET]motor jolt x1
Adjust height
Remote back: PRESS [SET]motor jolt x1

Delete favourite position

Move to the position to delete
Remote back: HOLD [SET]motor jolt x2
If the upper or lower limit has been deleted, the blind uses the closest favourite position as its upper or lower limit

Copy channel using remote — add channel or remote

Existing channel: HOLD [STOP]motor jolt x1
New channel: PRESS [UP]motor jolt x1

Delete channel on remote — delete channel or remote

Connected channel: HOLD [STOP]motor jolt x1
Channel to delete back: PRESS [SET]motor jolt x1

  • Set Favourite Position

  • Edit Favourite Position

  • Delete Favourite Position

  • Motor Power On

  • Motor Power Off

Transcribed from Speedy Blinds Louvolite One Touch R1918 guide (speedyblinds.au/motor/louvolite-wirefree), 2026-09-04. If a step here differs from the guide you were sent with the job, the guide is right. Tell us and we'll correct this page.
