Motor setup

Rollease Acmeda E6 ARC

Range
ACMEDA (Automate) Roller Blinds
Motor
E6 ARC — Wired AC Motor
Remote
Automate | 15CH ARC Remote
Power
Wired AC
Identify by
E6 ARC on the motor label or the job paperwork.
Work through a section in order. The response in the right column is how the motor confirms the step. If you don't get it, repeat that step rather than moving on. Stuck? Call 0436 666 687 with the model and what the motor is doing.

Before you start

  • Remote — insert battery.
  • Motor — connect power.

Initial setup

Factory reset motor

Motor: HOLD [BUTTON]jolt x4 & let go of button & beep x4

Pairing

Select channel
Motor: PLUG IN — or — HOLD [BUTTON]jolt & beep
Remote: HOLD [STOP]jolt x2 & beep x3

Reverse roll directionif required

Remote: HOLD [UP] [DOWN]motor jolt x1

Set limits

UP limit FIRST
Remote: HOLD [UP]continuous travel
Remote: PRESS [UP]step mode
Remote: HOLD [UP] [STOP]jolt x2 beep x3
DOWN limit SECOND
Remote: HOLD [DOWN]continuous travel
Remote: PRESS [DOWN]step mode
Remote: HOLD [DOWN] [STOP]jolt x2 beep x3

Adjust upper limit

Remote: HOLD [UP] [STOP]jolt & beep
Adjust height
Remote: HOLD [UP] [STOP]jolt x2 beep x3

Adjust lower limit

Remote: HOLD [DOWN] [STOP]jolt & extended beep
Adjust height
Remote: HOLD [DOWN] [STOP]jolt x2 beep x3

Copy channel using motor — add channel or remote

Select channel
Motor: HOLD [BUTTON]jolt & beep
New channel: HOLD [STOP]jolt x2 beep x3

Delete channel using motor — delete channel or remote

Select channel
Motor: HOLD [BUTTON]jolt & beep
Channel to delete: HOLD [STOP]jolt x2 beep x3

Delete all remotes connected to motor, using remote

Remote back: PRESS [P2]jolt & beep
Remote: PRESS [STOP]jolt & beep
Remote back: PRESS [P2]jolt x2 beep x3

Delete all limits on motor, using remote

Remote back: PRESS [P2]jolt & beep
Remote: PRESS [DOWN]jolt & beep
Remote back: PRESS [P2]jolt x2 beep x3

Hide / unhide channels

Remote: HOLD [+] [−]display 15
Select last channel to keep
Remote: PRESS [STOP]display oK

Lock / unlock limit setting on remote

Remote back: HOLD [TOP RIGHT]display L or U
U — unlocked
L — locked

Enable sleep mode

Motor: HOLD [BUTTON]jolt x2 & beep x2

Wake up

Motor: PRESS [BUTTON]roll to nearest limit

Switch between tilt & roll mode

Remote: HOLD [UP] [DOWN]motor jolt x1
Remote: PRESS [STOP]switch modes
Mode: TILT (hold Up or Down to roll) — jolt & beep
Mode: ROLL — jolt x2 beep x3

Two way (bidirectional) / one way (unidirectional) mode

Remote: Remove battery
Remote: HOLD [P2]
Remote: Put in battery
1 — Two way (bidirectional) mode (ARC only)
2 — One way (unidirectional) mode (EL only)

  • Factory Reset Motor

  • Pairing to Remote Control

  • Reverse Roll Direction

  • Set Limits

  • Adjust Upper Limit

  • Adjust Lower Limit

  • Copy Channel and Settings to Another Channel

  • Copy Channel and Settings to Another Remote

  • Delete Channel Using Remote

  • Copy Channel and Settings Using Motor

  • Delete Channel Using Motor

  • Delete All Remotes Connected to Motor

  • Delete and Reset All Limits on Motor

Troubleshoot

Work down the list before resetting anything.

  • Motor — check it has power.
  • Motor not in sleep mode.
  • Motor in roll mode.
  • Remote — check it has battery.
  • Remote unlocked.
  • Remote — unhide all channels.
  • Remote in two way (bidirectional) mode.
  • All else fails: factory reset.

  • Hide or Unhide Unused Channels on Remote

  • Lock or Unlock Limit Settings

  • Switch Between Two Way (Bidirectional) & One Way (Unidirectional) Modes on Remote

  • Switch Between Tilt and Roll Modes

User preferences

Set favourite position

Move to position
Remote back: PRESS [P2]jolt & beep
Remote: PRESS [STOP]jolt & beep
Remote: PRESS [STOP]jolt x2 beep x3

Move to favourite position

Remote: HOLD [STOP]

Delete favourite position

Remote back: PRESS [P2]jolt & beep
Remote: PRESS [STOP]jolt & beep
Remote: PRESS [STOP]jolt & beep

Copy channel using remote — add channel or remote

Existing channel back: PRESS [P2]jolt & beep
Existing channel back: PRESS [P2]jolt & beep
New channel back: PRESS [P2]jolt x2 beep x3

Delete channel using remote — delete channel or remote

Channel to keep back: PRESS [P2]jolt & beep
Channel to keep back: PRESS [P2]jolt & beep
Channel to delete back: PRESS [P2]jolt x2 beep x3

  • Set Favourite Position

  • Move to Favourite Position

  • Delete Favourite Position

  • Enable Sleep Mode

  • Wake Up from Sleep Mode

Transcribed from Speedy Blinds Acmeda E6 ARC guide (speedyblinds.au/motor/acmeda-e6), 2026-09-04. If a step here differs from the guide you were sent with the job, the guide is right. Tell us and we'll correct this page.

Other Rollease Acmeda guides: Zero ARC Wirefree.
