Motor setup
Rollease Acmeda Zero ARC Wirefree
- Range
- ACMEDA (Automate) Roller Blinds
- Motor
- Zero ARC Wirefree Li-ion 5V 1.1Nm Short | 1.1Nm | 2.0Nm — Battery DC Motor. Discontinued ARC Li-ion 12V 1.1Nm | Q2.0Nm (Quiet) | 3.0Nm | 10Nm — Battery DC Motor
- Remote
- Automate | 15CH ARC Remote
- Power
- Rechargeable battery DC
- Identify by
- Zero ARC on the label, and a 5V Micro USB charging port. Older 12V Acmeda battery motors are a different guide.
Work through a section in order. The response in the right column is how the motor confirms the step. If you don't get it, repeat that step rather than moving on. Stuck? Call 0436 666 687 with the model and what the motor is doing.
Before you start
- Remote — insert battery.
- Motor — fully charge (5V Micro USB).
Initial setup
Factory reset
| Motor: HOLD [BUTTON] | jolt x4 & beep x4 |
|---|
Pairing
| Select channel | |
| Motor: HOLD [BUTTON] | jolt & beep |
|---|---|
| Remote: HOLD [STOP] | jolt x2 & beep x3 |
Reverse roll directionif required
| Remote: HOLD [UP] [DOWN] | motor jolt x1 |
|---|
Set limits
| UP limit FIRST | |
|---|---|
| Remote: HOLD [UP] | continuous travel |
| Remote: PRESS [UP] | step mode |
| Remote: HOLD [UP] [STOP] | jolt x2 beep x3 |
| DOWN limit SECOND | |
| Remote: HOLD [DOWN] | continuous travel |
| Remote: PRESS [DOWN] | step mode |
| Remote: HOLD [DOWN] [STOP] | jolt x2 beep x3 |
Adjust upper limit
| Remote: HOLD [UP] [STOP] | jolt & extended beep |
|---|---|
| Adjust height | |
| Remote: HOLD [UP] [STOP] | jolt x2 beep x3 |
Adjust lower limit
| Remote: HOLD [DOWN] [STOP] | jolt & extended beep |
|---|---|
| Adjust height | |
| Remote: HOLD [DOWN] [STOP] | jolt x2 beep x3 |
Copy channel using motor — add channel or remote
| Select channel | |
| Motor: HOLD [BUTTON] | jolt & beep |
|---|---|
| New channel: HOLD [STOP] | jolt x2 beep x3 |
Delete channel using motor — delete channel or remote
| Select channel | |
| Motor: HOLD [BUTTON] | jolt & beep |
|---|---|
| Channel to delete: HOLD [STOP] | jolt x2 beep x3 |
Hide / unhide channels
| Remote: HOLD [+] [−] | display 15 |
|---|---|
| Select last channel to keep | |
| Remote: PRESS [STOP] | display oK |
Lock / unlock limit setting on remote
| Remote back: HOLD [TOP RIGHT] | display L or U |
|---|---|
| U — limit settings unlocked | |
| L — limit settings locked | |
Enable sleep mode
| Motor: HOLD [BUTTON] | jolt x2 beep x2 |
|---|
Wake up
| Motor: PRESS [BUTTON] | roll to nearest limit |
|---|
Switch between tilt & roll mode
| Remote: HOLD [UP] [DOWN] | motor jolt x1 |
|---|---|
| Remote: PRESS [STOP] | switch modes |
| Mode: TILT (hold Up or Down to roll) — jolt & beep | |
| Mode: ROLL — jolt x2 beep x3 | |
Two way (bidirectional) / one way (unidirectional) mode
| Remote: Remove battery | |
|---|---|
| Remote: HOLD [P2] | |
| Remote: Put in battery | |
| 1 — Two way (bidirectional) mode (ARC motors only) | |
| 2 — One way (unidirectional) mode (EL motors only) | |
Factory Reset Motor
Pairing to Remote Control
Reverse Roll Direction
Set Limits
Adjust Upper Limit
Adjust Lower Limit
Copy Channel and Settings to Another Channel
Copy Channel and Settings to Another Remote
Delete Channel Using Remote
Copy Channel and Settings Using Motor
Delete Channel Using Motor
Troubleshoot
Work down the list before resetting anything.
- Motor — check it has power.
- Motor not in sleep mode.
- Motor in roll mode.
- Remote — check it has battery.
- Remote unlocked.
- Remote — unhide all channels.
- Remote in two way (bidirectional) mode.
- All else fails: factory reset.
Hide or Unhide Unused Channels on Remote
Lock or Unlock Limit Settings on Remote
Switch Between Two Way (Bidirectional) & One Way (Unidirectional) Modes on Remote
Switch Between Tilt and Roll Modes
User preferences
Set favourite position
| Move to position | |
| Remote back: PRESS [P2] | jolt & beep |
|---|---|
| Remote: PRESS [STOP] | jolt & beep |
| Remote: PRESS [STOP] | jolt x2 beep x3 |
Move to favourite position
| Remote: HOLD [STOP] |
|---|
Delete favourite position
| Remote back: PRESS [P2] | jolt & beep |
|---|---|
| Remote: PRESS [STOP] | jolt & beep |
| Remote: PRESS [STOP] | jolt & beep |
Copy channel using remote — add channel or remote
| Existing channel back: PRESS [P2] | jolt & beep |
|---|---|
| Existing channel back: PRESS [P2] | jolt & beep |
| New channel back: PRESS [P2] | jolt x2 beep x3 |
Delete channel using remote — delete channel or remote
| Channel to keep back: PRESS [P2] | jolt & beep |
|---|---|
| Channel to keep back: PRESS [P2] | jolt & beep |
| Channel to delete back: PRESS [P2] | jolt x2 beep x3 |
Increase speed3 speeds available: low / med / high
| Remote back: PRESS [P2] | jolt & beep |
|---|---|
| Remote: PRESS [UP] | jolt & beep |
| Remote: PRESS [UP] | jolt x2 beep x1 |
Decrease speed3 speeds available: low / med / high
| Remote back: PRESS [P2] | jolt & beep |
|---|---|
| Remote: PRESS [DOWN] | jolt & beep |
| Remote: PRESS [DOWN] | jolt x2 beep x1 |
Soft stop offmotor must be on LOW speed setting
| Remote back: PRESS [P2] | jolt & beep |
|---|---|
| Remote: PRESS [DOWN] | jolt & beep |
| Remote: PRESS [DOWN] | jolt & beep |
Soft stop onmotor must be on HIGH speed setting
| Remote back: PRESS [P2] | jolt & beep |
|---|---|
| Remote: PRESS [UP] | jolt & beep |
| Remote: PRESS [UP] | jolt & extended beep |
Battery checkmotor must be at upper limit
| Remote: HOLD [UP] | % of fabric is % of charge remaining |
|---|
Charging LED on/offmotor must be at lower limit
| Remote: HOLD [DOWN] | motor light flash x3 — toggle ON/OFF |
|---|
Set Favourite Position
Move to Favourite Position
Delete Favourite Position
Enable Sleep Mode
Wake Up from Sleep Mode
Increase Motor Speed
Decrease Motor Speed
Soft Stop On
Soft Stop Off
Battery Check Function
Charging LED On/Off
